ELING 6 Gauge Kit 85mm Speedometer GPS 200KM/H Odometer Tachometer 8000RPM Meter Fuel Level 0-190ohm Water Temp. 0-120℃ Oil Pressure 0-10Bar 0-150Psi Voltmeter 12V with 7 Colors Backlight Waterproof
4.8 (57 items)
Limited Time Sale$105.59 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 234070493 | Release Date | 2026/06/27 | List Price | $70.40 | Model Number | 234070493 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- 6 Gauge Set-GPS Speedometer, Tachometer, Fuel Level Gauge, Water Temperature Gauge, Oil Pressure Gauge and Voltmeter. Backlight: 7 Backlights available (red, green, blue, white, yellow, cyan, purple)
- 6 Gauge Set-GPS Speedometer gauge indicating Range: 0-200KM/H, Tachometer indicating Range: 0-8000 RPM, Fuel Level Gauge indicating Range: E-1/2-F, Water Temperature Gauge indicating Range: 0-120℃, Oil Pressure Gauge indicating Range: 0-10Bar 0-150Psi, Voltmeter indicating Range: 8-16V.
- 6 Gauge Set-GPS Speedometer's signal: GPS signal, Tachometer's signal: Pulse signal, Fuel Level Gauge's Signal: 0-190ohm, Water Temperature Gauge's Signal: 1600-22ohm, Oil Pressure Gauge's Signal: 10-184ohm.
- GPS Speedometer and Tachometer's installtion:Cut an 85mm (3 3/8") hole in the panel and allow a clearance of 55mm (2 3/16”) behind the panel to fit the gauge. Put the gauge in the hole and screw down. Fuel Level Gauge, Water Temperature Gauge, Oil Pressure Gauge and Voltmeter's installtion: Cut an 52mm (2 1/16") hole in the panel and allow a clearance of 55mm (2 3/16”) behind the panel to fit the gauge. Put the gauge in the hole and screw down.
- For the GPS antenna, you should securely fasten it in the flat position, black side upwards, preferably outside (or inside front windscreen) so that it has a clear view of the sky to pick up satellite signal. Connect the antenna cable to socket in the back of the gauge. And do not cut cable.
| ASIN | B0CMSWDQXV |
|---|---|
| Brand Name | ELING |
| Item Weight | 1 Kilograms |
| Part Number | EL0839EL0848 |
| Manufacturer | ELING |
| Material Type | Stainless Steel |
| Item Dimensions | 11.02 x 3.15 x 8.46 inches |
| Included Components | Gauge and Sensor |
| Warranty Description | 1 year |
